1J21 Soft Magnetic Alloy

1J21 is a high-performance soft magnetic alloy with the highest saturation magnetic induction (up to 2.4T) and low iron loss, representing the top tier in soft magnetic materials. Its key feature is delivering extremely high magnetic induction while maintaining low energy loss. Key Properties & Advantages High Saturation Magnetic Induction (2.4T): enables higher magnetic flux density. Low Core Loss: improves motor and generator efficiency while reducing energy loss. High Power Density & Efficiency: supports maximum torque density and compact motor design. Wide Applications: excellent performance in electrical, medical, and other specialized fields. Typical Applications Motor and generator cores — improve power density and efficiency Electromagnetic poles — medical radiology equipment Specialized transformers Magnetic bearings Actuators and magnetic components Mechanical Properties (Hardened, Rod Example) Tensile strength Rm ≈ 260MPa Yield strength Rp0.2 ≈ 185MPa Elongation A ≈ 0.66% Machinability In the hardened state, 1J21 exhibits high brittleness and low ductility, making it prone to chipping and edge breakage during machining. Advanced machining techniques, proper tooling materials, and optimized cutting parameters are required. Supply Forms Specifications: rod, plate, strip, wire Conditions: cold-rolled, annealed Customization:tailor-made processing available upon request

1J27 Soft Magnetic Alloy

1J27 is a Fe-Co-Cr soft magnetic alloy featuring exceptional ductility and toughness, ranking among the most formable materials in the family of high-saturation magnetic induction and high-Curie-temperature Fe-Co based soft magnetic alloys. Its saturation magnetic induction is nearly equivalent to that of 1J22, while offering significantly better mechanical strength and toughness, thus avoiding the brittleness and cracking tendency often seen in 1J22. 1J27 is ideal for applications that demand a combination of high magnetic saturation, excellent ductility, and superior toughness. Key Properties & Advantages High saturation magnetic induction (comparable to 1J22) High curie temperature, suitable for high-temperature magnetic environments Excellent ductility and impact resistance for demanding applications Low magnetic loss and stable magnetic performance Good processability, suitable for both cold and hot forming Typical Applications Cores and rotors for high-speed electric motors Generators and electromagnetic actuators Aerospace and aviation magnetic systems Precision magnetic components requiring both high saturation and toughness Mechanical Properties (Strip Example) Tensile strength Rm ≤ 570MPa Yield strength Rel0.2 ≤ 400MPa Elongation A ≥ 18% Vickers Hardness ≤ 180HV Supply Forms Specification: strip, sheet, and bar Condition: cold-rolled, annealed Customization: available upon request Standards: specifications available according to Russian, American, British, French, and Japanese standards

Nickel Alloys & Iron-Nickel Alloys

Nickel Alloys & Iron-Nickel Alloys – High-Performance Metals for Extreme Environments Key Material Advantages High-Temperature Strength: Nickel-based alloys maintain structural integrity under extreme heat. Low Thermal Expansion: Iron-nickel alloys ensure precision and dimensional stability. Corrosion & Oxidation Resistance: Reliable performance in chemical, marine, and industrial environments. Durable Mechanical Properties: Long-lasting under stress, fatigue, and vibration. Customizable Designs: Supports special geometries, surface treatments, and alloy grades. Common Grades Nickel Alloys: Inconel Series: Inconel 600, 625, 718–High-temperature and corrosion-resistant superalloys for aerospace and energy industries Hastelloy Series: Hastelloy C-22, C-276–Excellent chemical resistance for industrial and marine applications Monel Alloys: Monel 400, K500–Corrosion-resistant alloys suitable for marine and acidic environments Pure Nickel Grades: Nickel 200, 201–High electrical and thermal conductivity for electronics and industrial components Iron-Nickel Alloys: Invar (36% Ni): Low thermal expansion for precision instruments, optical devices, and aerospace structures Kovar (29% Ni, 17% Co): Matched thermal expansion for glass-to-metal sealing in electronics and semiconductors Alloy 42: Controlled expansion for industrial electronics and precision assemblies Product Forms Available Bars, Plates, Pipes, Strips Forgings: Rings, shafts, discs, customized shapes Custom Machined Parts: According to drawings and specifications Heat Treatment & Surface Finishing: Anodizing, sandblasting, precision polishing, coating, and other treatments Applications Aerospace & Aviation: Turbine components, engine parts, structural assemblies Chemical & Marine: Reactors, piping, pumps, seawater-resistant components Electronics: Vacuum tubes, semiconductor packages, sensor parts Power Generation & Energy: Boilers, heat exchangers, and industrial processing equipment Precision Machinery: Measurement instruments, semiconductor packaging, satellite components Why Choose Us Support for both small-batch customization and bulk supply Full-process services including forging, machining, and heat treatment Drawing-based production with support for third-party inspection and certification Fast export handling with full support for international logistics and customs clearance Contact us for tailored solutions and competitive offers！

Stainless Steels

Stainless Steels – Durable, Corrosion-Resistant, and Versatile Key Material Advantages Excellent Corrosion Resistance: Resists rust and chemical attack in various environments including marine, acidic, and high-humidity conditions High Mechanical Strength: Maintains toughness and fatigue resistance across a wide range of temperatures Hygienic and Easy to Clean: Non-reactive with food, pharmaceuticals, and chemicals, ideal for sanitary and medical applications Good Formability and Weldability: Suitable for stamping, bending, machining, and welding, maintaining consistent surface quality Aesthetic Appeal: Offers a clean, modern appearance with various finishes (mirror, brushed, matte) Common Grades Austenitic Stainless Steels: 304 (S30400), 316 (S31600), 321 – Most widely used, combining outstanding corrosion resistance and excellent formability. Ferritic Stainless Steels: 430, 409 – Cost-effective with good resistance to oxidation and stress corrosion cracking. Martensitic Stainless Steels: 410, 420 – High hardness, strength, and wear resistance for industrial and tooling applications. Duplex Stainless Steels: 2205, S31803 – Superior pitting resistance and high strength for harsh chemical and marine environments. Precipitation-Hardening (PH) Grades: 17-4PH (S17400), 15-5PH – Heat-treatable stainless steels with high strength and excellent corrosion resistance. Product Forms Available Bars, Plates, Pipes, Strips Forgings: Rings, shafts, discs, customized shapes Custom Machined Parts: According to drawings and specifications Heat Treatment & Surface Finishing: Anodizing, sandblasting, precision polishing, coating, and other treatments Applications Construction & Architecture: Structural components, facades, handrails, fittings Food & Pharmaceutical Equipment: Tanks, pipelines, sanitary equipment Energy & Chemical Industry: Heat exchangers, pressure vessels, valves, pipelines Automotive & Transportation: Exhaust systems, chassis, engine parts Medical Equipment: Surgical instruments, implants, medical devices Why Choose Us Support for both small-batch customization and bulk supply Full-process services including forging, machining, and heat treatment Drawing-based production with support for third-party inspection and certification Fast export handling with full support for international logistics and customs clearance Contact us for tailored solutions and competitive offers！

Aluminum Alloys

Aluminum Alloys – Lightweight, Versatile, High-Performance Materials Key Material Advantages Lightweight and Strong: Approximately one-third the density of steel, with strength enhanced by alloying – ideal for structural components Excellent Workability: Suitable for forging, extrusion, milling, welding, and other processing methods Corrosion Resistance: Naturally forms a protective oxide layer, enhancing durability in atmospheric and chemical environments High Thermal and Electrical Conductivity: Perfect for heat sinks, conductors, and power system components Attractive Appearance and Anodizing Potential: Easily surface-treated to improve aesthetics and corrosion protection Common Aluminum Alloy Series 1xxx Series: Commercially pure aluminum, excellent conductivity and corrosion resistance 2xxx Series: Aluminum-copper alloys, high-strength structural components 5xxx Series: Aluminum-magnesium alloys, excellent corrosion resistance and weldability, widely used in marine and automotive sectors 6xxx Series: Aluminum-magnesium-silicon alloys, balance of strength and processability, highly versatile 7xxx Series: Aluminum-zinc alloys, ultra-high strength, mainly for aerospace applications Product Forms Available Bars, Plates, Pipes, Strips Forgings: Rings, shafts, discs, customized shapes Custom Machined Parts: According to drawings and specifications Heat Treatment & Surface Finishing: Anodizing, sandblasting, precision polishing, coating, and other treatments Applications Aerospace & Aviation: Aircraft structures, brackets, fuselage panels Automotive & Transportation: Chassis, engine parts, heat exchangers, body panels Industrial Equipment: Machinery frames, structural supports, conveyors Construction & Architecture: Facade panels, window frames, curtain walls Marine & Energy: Boat hulls, offshore structures, conductive components Why Choose Us Support for both small-batch customization and bulk supply Full-process services including forging, machining, and heat treatment Drawing-based production with support for third-party inspection and certification Fast export handling with full support for international logistics and customs clearance Contact us for tailored solutions and competitive offers！

1J22QB Soft Magnetic Alloy

1J22QB is a tough and durable soft magnetic alloy with high saturation magnetic induction. Compared with traditional 1J22, it offers significantly enhanced machinability, effectively minimizing tooth breakage, chipping, and cracking during manufacturing. This alloy retains its core high magnetic performance while improving overall reliability in high-speed rotation and complex assembly environments, making it ideal for demanding motor and precision electromagnetic applications. Key Properties & Advantages High Toughness: reduces part damage during machining and assembly Excellent Machinability: minimizes chipping, cracking, and tool wear, improving production efficiency High Magnetic Performance: maintains superior magnetic induction for advanced motor systems Outstanding Reliability: performs consistently in high-speed and complex operating environments Stable Processing Performance: reliable in stamping, cutting, and heat treatment processes Typical Applications High-speed aerospace motors Railway traction motors Servo motors and generators requiring precision control Electromagnetic devices and specialized motor components Mechanical Properties (Strip 0.2mm) Tensile strength Rm ≥ 300MPa Yield strength Rel0.2 ≥ 270MPa Elongation A ≥ 1.5% Supply Forms Specification: bar Condition: cold-rolled, annealed Customization: available upon request Standards: specifications available according to Russian, American, British, French, and Japanese standards

1J22Q Soft Magnetic Alloy

1J22Q is a newly developed material optimized and improved on the basis of traditional 1J22 soft magnetic alloy. It not only retains the core advantage of 1J22 alloy with high saturation magnetic induction, but also achieves significant improvement in mechanical properties.
Compared with ordinary 1J22, 1J22Q has higher mechanical strength, effectively reducing the risk of fracture of motor laminations during punching and assembly, and is particularly suitable for high-speed and high-rotation motor applications.

Key Properties & Advantages
Enhanced magnetic performance: all indicators exceed Chinese Standard GB/T 14986.3-2018
Higher mechanical strength: significantly improves rotor lamination structural strength
Improved reliability: reduces fracture risk and extends motor service life
High-speed adaptability: suitable for high-speed rotation, ensuring motor stability

Typical Applications
Aerospace motors
High-speed railway traction motors
High-performance servo motors and generators
Special electromagnetic devices

Mechanical Properties (Strip 0.2mm)
Tensile strength Rm ≈ 800MPa
Yield strength Rel0.2 ≈ 350MPa
Elongation A ≈ 8%

Supply Forms
Specification: strip
Condition: cold-rolled, annealed
Customization: available upon request
Standards: specifications available according to Russian, American, British, French, and Japanese standards
